Home » Electric Transformers

Call Us : +91-8048077608

Electric Transformers

We design and produce electric transformers which includes distribution transformers, furnace transformers, single phase transformers, earthing transformers, three phase transformers, dry type transformers, rectifier transformers, reactor transformers, converter duty transformers. Our offered transformers are precisely designed and developed utilizing unmatched quality raw materials and are available at the most competitive prices. We also provide these transformers on rent.

Distribution Transformers

Industrial, Substation & Distribution Tfr. Upto 10 MVA, Upto 33kV, ONAN

A poly phase transformer design is presented in which transformer output pores are accurately constructed in both voltage magnitude and relative phase angle. The design of these distribution transformers, electrical substation transformers incorporates both main and auxiliary transformers that are used in unison to produce the accurately constructed phases. The main transformer permits rough phase adjustment to be made with the auxiliary transform permitting phase fine tuning. Such a design is particularly suitable in transformer approaches that require output phases that are of a number not evenly divisible by three.
Distribution Transformers
Click here to view details

Power Transformers

Power Transformers
Station & Multi-winding to suit specific needs & L.T. Transformers for generating Stations.
Upto 10 MVA, 3 Phase, Upto 33Kv, ONAN/ONAF/OFAF/OFWF Cooling

Electrical power transformers characterized by inner and outer low voltage winding sections and a high voltage winding section disposed there between. The low voltage windings are comprised of a plurality of pancake coils, and the high voltage winding are comprised of a plurality of conductor strands spirally wound for a plurality of coil layers in these substation power transformers. The low and high voltage winding sections are laterally spaced with the low voltage windings disposed in side-by-side positions and adjacent to the high voltage windings. The high voltage windings having a smaller turn height than the low voltage windings and having conductor strands of smaller gauge than the pancake coils of the low voltage windings.
Click here to view details

Furnace Transformers

Furnace transformers are suitable for Arc furnace/ submerged arc furnace/ induction furnace duty are available up to capacity of 10 MVA with primary voltage up to 33 KV class and secondary voltages to suit furnace specification. Secondary voltages option can be made available by providing primary taps which will be either connected to off circuit manually operated, motorized or remote on load tap changer(OLTC) as per requirement.

Generally furnace transformers are with OFWF cooling. However, ONAN cooling can also be designed as per requirement.

For Arc furnace Transformers, if required, suitable series reactors can be supplied to reduce the short circuit stresses generated in transformer during the furnace operation.

These Transformers are designed to withstand the harmonics generated due to furnace operation.
Furnace Transformers
Click here to view details

Earthing Transformers

Earthing Transformers
These earthing transformers are used basically in neutral earthing of HV windings. They are equipped with the range up to 2 MVA, and a voltage up to 33 KV. It's a long lasting and low maintenance product at a competitive price. Automatic on/off cooling is available with this transformer
Click here to view details

Rectifier Transformers

Rectifier transformers are suitable for 6 pulse or 12 pulse operation with options of different winding connections on primary & secondary winding with or without inter phase transformer.
The capacity range up to 10 KA DC with primary voltage up to 33 KV.
The option of cooling i.e. ONAN/ONAF/ OWFW is available.
The rectifier transformer is designed suitably for the harmonics generated in the system so that overheating of core and windings is avoided.
Rectifier Transformers
Click here to view details

Reactor Transformers

Reactors Transformers
This is an air cored series & shunt reactor. With a range up to 2 MVA, and a voltage up to 33 KV. It comes with the facility of automatic on/off cooling. The feedback of this product has been satisfactory from our clients. We offer this durable reactor at competitive price range.
Click here to view details

Converter Duty Transformers

This product is used as set up transformer from generator to line voltage. Converter Duty Transformers has a range up to 10 MVA, and the voltage capacity of up to 33 KV. It's very durable and hassle free to be used by desired clients, it comes with an automatic on/off cooling option. We offer these converter duty transformers at a competitive price.
Converter Duty Transformers
Click here to view details

Dry Transformers (VPI)

Dry Transformers (VPI)
Industrial,substation & distribution up to 2 mva and 11 Kv with AN Cooling systems
Click here to view details





Our Products
Distribution TransformersPower TransformersFurnace TransformersEarthing Transformers
Rectifier TransformersReactor TransformersConverter Duty TransformersDry Transformers (VPI)


Looking for Product Name ?
